MAVAL

Steering Gear Box - MAVAL - Hydraulic Power - Remanufactured -98218M

Steering Gear Box - MAVAL - Hydraulic Power - Remanufactured -98218M

SKU:98218M

MAVAL steering gear boxes are remanufactured and tested to OEM specifications. Our process includes the inspection and replacement of worm/thrust bearings, bushings, and the inspection of ball guides, balls, and the sector shaft. All original snap rings and O-rings are replaced. Each steering gear box has the MAVAL part number etched into the housing as well as a serial number for traceability. All MAVAL gear boxes are 100 percent lash calibrated for precision performance.

New Or Remanufactured Remanufactured
Hose Port Type Seat
Input Shaft Diameter 0.875
Input Shaft Diameter 22.23 mm
Steering Input Shaft Spline Quantity 31
Input Shaft Type Splined
Number of Mounting Holes 4
Output Shaft Diameter 0.864
Output Shaft Diameter 21.95 mm
Pitman Arm Included no
Pressure Port Thread Size 11/16-18
Return Port Thread Size 5/8-18
Rotation Dirrection Standard
Total Turns Lock To Lock 3.5



Application Info: 1971-1973 Buick Centurion; 1964-1976 Buick Electra; 1964-1976 Buick Estate Wagon; 1971-1976 Buick LeSabre

Interchange:

BBB Cross-Reference: N502-0104

Cardone Cross-Reference: 27-6529, 97-6529GB

Instructions - 1               Instructions - 2
