MAVAL

Rack and Pinion Assembly - MAVAL - Hydraulic Power - Remanufactured - 95423M

Rack and Pinion Assembly - MAVAL - Hydraulic Power - Remanufactured - 95423M

SKU:95423M

MAVAL rack and pinions come turn-key ready for installation. They include, re-certified or new inner tie-rod ends, new bellows, fasteners, and the replacement of seals and O-rings. Pinion valves are performance tested and the unit's electronic solenoids are performance verified. In addition, all MAVAL remanufactured rack and pinions are centered before leaving the test stand, reducing install time. Each rack and pinion have the MAVAL part number etched into the housing as well as a serial number for traceability.

Casting Material Steel; Aluminum
Distance Between Mounting Holes 6.75 IN
Distance Between Mounting Holes 171.45 MM
Hose Port Type O-Ring
Input Shaft Diameter 0.75 IN
Input Shaft Diameter 19.05 MM
Input Shaft Length 2.25 IN
Input Shaft Length 57.15 MM
Mounting Hole Quantity 2
Pressure Port Thread Size M18 x 1.5
Rack Length 48 IN
Rack Length 1219.2 MM
Return Port Thread Size M16 x 1.5
Thread Length 2.25 IN
Thread Length 57.15 MM
Inner Tie Rods Included Yes
Total Turns Lock To Lock 3.13

Application Info: Dodge Stratus 2005-2006 - Sedan w/Std. Steering.

Interchange: Chrysler - 4764920AI

BBB Cross-Reference: 102-0158

Cardone Cross-Reference: 22-353
