Power Steering Pump - MAVAL - Hydraulic Power - Remanufactured - 96105M

Power Steering Pump - MAVAL - Hydraulic Power - Remanufactured - 96105M

SKU:96105M

MAVAL power steering pumps come turn-key ready for installation. The pressure fitting and pressure relief valve of the pump are inspected while the existing seals and bearings are replaced with OEM parts. The rotor, cam ring, vanes and pressure plates are inspected and replaced as needed during the reman process. Each pump has the MAVAL part number etched into the housing as well as a serial number for traceability.

Hose Port Type Washer
Housing Material Cast Iron
Mounting Hardware Included No
Outlet Thread Size 16X1.5
Inlet Attachement Type Hose Barb
Outlet Attachment Type Threaded
Outlet Quantity 1
Reservoir Cap Included No
Pulley Attachment Type Bolt-on
Pulley Included No
Remote Reservoir No
Reservoir Included Yes

Application Info: Isuzu Impulse 1985-1989 - JR Models w/4ZC1 Engine

Interchange: Isuzu - 4402-409-1

BBB Cross-Reference: 990-0324

Cardone Cross-Reference: 21-5745
