MAVAL

Power Steering Pump - MAVAL - Hydraulic Power - Remanufactured - 97118M

Power Steering Pump - MAVAL - Hydraulic Power - Remanufactured - 97118M

SKU:97118M

MAVAL power steering pumps come turn-key ready for installation. The pressure fitting and pressure relief valve of the pump are inspected while the existing seals and bearings are replaced with OEM parts. The rotor, cam ring, vanes and pressure plates are inspected and replaced as needed during the reman process. Each pump has the MAVAL part number etched into the housing as well as a serial number for traceability.

Hose Port Type O-Ring
Housing Material Aluminum
Mounting Hardware Included No
Outlet Thread Size 16X1.5
Inlet Attachement Type Hose Barb
Outlet Attachment Type Threaded
Outlet Quantity 1
Pulley Attachement Type Press-on
Pulley Included No
Remote Reservoir No
Reservoir Included No

Application Info: Dodge Ram 1500 Extended Crew Cab (2008), Ram 2500 (2003-09), Ram 3500 (2003-09), Ram 4500 (2008-09), Ram 5500 (2008-09) ***ZF Pump, W/Bolt-On Backing Plate, W/O Pulley, W/O Reservoir***

Interchange: 52013978AA, 52013978AB, 52013978AC, 52013978AD, 52013979AB, 52013979AC, 52013979AD, 52106842AC, 52106842AG, 52113925AF, 52113925AH, 52121690AA, 52121690AB, 68034326AA, 68034326AB, 68034330AA, 68034330AB

BBB Cross-Reference: 950-0118

Cardone Cross-Reference: 20-1008

Instructions - 1          Instructions - 2

Instructions - 3          Instructions - 4

Instructions - 5          Instructions - 6
